Feature:

• Interior of oven is made of specular steel by argon-arc-welding technics, and the exterior of oven is made of high-quality steel sheet with a beautiful and novel appearance.
• Microprocessor PID temperature controller with temperature control protection, digits display and timing function ensures a precise and reliable temperature control. (Intelligent programmable LCD temperature controller is an option).
• Hot-air circulating system consists of a fan keeping funning under a high temperature and proper air ducts to ensure a uniform distribution of temperature in chamber.
• Independent alarm system for temperature-limiting ensures experiments fun safely and no accident would happen. (Option)
• Recorder and printer are options which can print or record setting parameters and tracing variation curves of temperature. (Option)

Options:

• Intelligent programmable LCD temperature controller
• Independent temperature-limiting controller
• RS485 Socket



Model	DHG-9023A	DHG-9053A	DHG-9123A	DHG-9203A
Electrical Requirements	220V 50HZ
Input Power	500W	750W	1500W	2000W
Temperature Range	Rt+10~250℃
Temperature Control	0.1℃
Temperature Stability	±0.5℃
W*D*H Interior Dimension(mm)	300*300*270	420*350*350	550*350*550	600*550*600
W*D*H Overall Dimension(mm)	500*450*440	710*520*520	840*530*730	890*730*780
Shelves per Chamber	2pcs
Time Range	1~9999(min)
